Material Used
| Pump Casing | PP TV 40 |
| Gland Housing | PP GF 15 |
| Impeller (BADU47/5, BADU47/10, 47/16) | PA 66 GF 30/PC |
| Impeller (BADU47/22) | PA 66 GF 30 |
| Union Glue Socket | ABS ABS |
| Mechanical Seal | carbon/ceramic/NBR |
| Bolts | brass/stainlessteel |
Model Data
| Model | BADU 47/16 |
BADU 47/22 |
| Inlet / Outlet | 1 1/2” / 2” | 1 1/2” / 2” |
| Rec. Pipe | 2“ | 2“ |
| Casing Pressure | 2.5 Bar | 2.5 Bar |
| Motor | Class B | Class F |
| Voltage (V) | 1~230V | 1~230V |
| Current (A) | 4.7 | 5.3 |
| Power input P1(kW) | 0.97 | 1.2 |
| Power output P2(kW) | 0.65 | 0.8 |
| Weight (kg) | 8.1 | 10.4 |
